Mast type(標準門架)
2級門架/高視野

Capacity A(額定載荷 A)
2000 kg (4,409.25 lb)

Load Centre (中心) A(載荷中心A)
500 mm (19.69 in)

Operator position(操作員座位方位)
Sit down(座駕式)

Notes(備注)
Oil cooled Disc Brake

Drawbar pull (max.)(最大牽引力)
1240 kg

Lift speed, with load(提升速度,滿載)
280 mm / sec. (11.02 in/sec)

Lift speed, no load(提升速度,空載)
560 mm / sec. (22.05 in/sec)

Travel speed forward, with load(行駛速度,滿載)
11.8 kph (7.33 mph)

Travel speed forward, no load(行駛速度,空載)
12.5 kph (7.77 mph)

Climbing performance, with load (%)(爬坡能力, 滿載 (%))
23.1

Electric system(電動系統)
Battery(電池)

Battery(電池)
850AH

Voltage(電壓)
36V

Traction motor, output
3.6x2 KW

Lift pump motor, output
7.8 KW (10.46 HP)

Max. lift height(最大提升高度)
3000 mm (118.11 in)

Free lift(自由提升高度)
130 mm (5.12 in)

Lowered height(縮回高度)
2000 mm (78.74 in)

Machine length(車體長度)
1997 mm (78.62 in)

Outside turning radius(轉彎半徑)
1626 mm (64.02 in)

Machine weight (no load)(自重,空載)
3577 kg (7,885.94 lb)

Wheel number(輪胎數量)
3

Wheels driven(驅動輪數量)
2

Tyres, type(輪胎類型)
Cushion(實心輪胎)

Tyre size(輪胎尺寸), front(前輪尺寸)
18x7x12.12

Tyre size(輪胎尺寸), rear(后輪尺寸)
18x7x12.12

Brakes, type (service)(剎車類型)
Oil cooled Disc Brake
