Fuel type(燃料類型) |
柴油 |
|
Mast type(標準門架) |
2 stage(2級門架) / 3 stage(三級門架) |
|
Capacity A(額定載荷 A) |
2500 kg (5,511.56 lb) |
|
Load Centre (中心) A(載荷中心A) |
500 mm (19.69 in) |
|
Notes(備注) |
4x2 and 4x4 available. Specs for 4x4 |
|
Travel speed forward, no load(行駛速度,空載) |
20 kph (12.43 mph) |
|
Climbing performance, with load (%)(爬坡能力, 滿載 (%)) |
38 |
|
Engine, make(發動機制造商) |
Kubota |
|
Engine, model(發動機型號) |
V2003T |
|
Rated power(額定功率) |
41.8 KW |
|
@ rpm(發動機額定轉速) |
2800 |
|
Transmission, type(傳動類型) |
Hydrostatic(靜壓) |
|
Max. lift height(最大提升高度) |
3300 mm (129.92 in) |
|
Lowered height(縮回高度) |
2460 mm (96.85 in) |
|
Machine length(車體長度) |
2630 mm (103.54 in) |
|
Machine width(車體寬度) |
1810 mm (71.26 in) |
|
Machine wheel base(軸距) |
1850 mm (72.83 in) |
|
Outside turning radius(轉彎半徑) |
4400 mm (173.23 in) |
|
Right angle stacking aisle(直角堆垛通過的最小寬度) |
2900 mm (114.17 in) |
|
Machine weight (no load)(自重,空載) |
4300 kg (9,479.88 lb) |
|
Wheel number(輪胎數量) |
4 |
|
Wheels driven(驅動輪數量) |
4 |
|
Tyres, type(輪胎類型) |
Pneumatic(充氣輪胎) |
|
Tyre size(輪胎尺寸), front(前輪尺寸) |
12.5/80-18 |
|
Tyre size(輪胎尺寸), rear(后輪尺寸) |
100/75-15.3 |
|
Brakes, type (service)(剎車類型) |
Hydraulic(液壓) multi-disc |
